Fanuc Spindle Amplifier Alarm 58

FANUC Alarm Codes >> FANUC Spindle Amplifier Alarms >> Spindle Amplifier Alarm 58

Disclaimer: Attempting repairs yourself can be dangerous and can void your warranty. Contact us for support.


FANIC Spindle Amplifier Alarm Code 58



Models AffectedDescriptionTroubleshooting

Fanuc 6072, 6078, 6082, 6088, 6102 amps
Fanuc 6111, 6112, 6116, 6141, 6142 amps

The temperature of the main circuit-cooling fan of the PSM is abnormally high.
  1. If the PSM indicates alarm code 3
    1. Troubleshoot according to the description of alarm code 3 provided in Section 3.1 of Part II.
  2. If the PSM indicates no alarm.
    1. A cable is faulty. The connection cable between the PSM (JX1B) and SPM (JX1A) is faulty. Replace the cable.
    2. The SPM is faulty. Replace the SPM or SPM control printed circuit board.



Relevant 6078 alpha spindle amplifiers to the 58 alarm:

Relevant 6082 alpha spindle amplifiers to the 58 alarm:

Relevant 6088 alpha spindle amplifiers to the 58 alarm:

Relevant 6102 alpha spindle amplifiers to the 58 alarm:

Relevant 6111 spindle amplifiers to the 58 alarm:

Relevant 6112 spindle amplifiers to the 58 alarm:

Relevant 6116 spindle amplifiers to the 58 alarm:

Relevant 6141 spindle amplifiers to the 58 alarm:

Relevant 6142 spindle amplifiers to the 58 alarm:
